Structural Reviewer Part 2 - Quiz

Architecture Board exam


Questions and Answers
  • 1.

    The strength reduction factor for flexure without tension

    • A.

      0.85

    • B.

      0.75

    • C.

      0.70

    • D.

      0.90

    • E.

      None of the above

    Correct Answer
    D. 0.90
    Explanation
    The strength reduction factor for flexure without tension is 0.90. This factor is used to reduce the strength of a member or structure when it is subjected to bending without any tension. It accounts for the reduced capacity of the member in flexure due to factors such as cracking, deflection, and other limitations. By applying this reduction factor, the design ensures a more conservative and safe approach by considering the reduced strength in flexure without tension.

    Rate this question:

  • 2.

    The strength reduction factor for axial tension and axial tension w/ flexure

    • A.

      0.90

    • B.

      0.85

    • C.

      0.70

    • D.

      0.75

    • E.

      None of the above

    Correct Answer
    A. 0.90
    Explanation
    The strength reduction factor for axial tension and axial tension with flexure is 0.90. This factor is used to reduce the nominal strength of a member to account for uncertainties and potential variations in material properties, construction practices, and loadings. It ensures a higher level of safety by reducing the design strength of the member.

    Rate this question:

  • 3.

    The strength reduction factor for shear and torsion

    • A.

      0.90

    • B.

      0.75

    • C.

      0.70

    • D.

      0.60

    • E.

      None of the sbove

    Correct Answer
    E. None of the sbove
  • 4.

    The strength reduction factor for axial compression and axial compression with flexure for spiral reinforcement

    • A.

      0.75

    • B.

      0.60

    • C.

      0.85

    • D.

      0.90

    Correct Answer
    A. 0.75
    Explanation
    The strength reduction factor for axial compression and axial compression with flexure for spiral reinforcement is 0.75. This means that the strength of the structure is reduced by 25% when considering axial compression and axial compression with flexure and using spiral reinforcement. This reduction factor is important in determining the design and safety of the structure, as it accounts for the behavior of the spiral reinforcement under these loading conditions.

    Rate this question:

  • 5.

    The strength reduction factor for axial compression and axial compression with flexure for tie reinforcement

    • A.

      0.75

    • B.

      0.85

    • C.

      0.70

    • D.

      0.90

    Correct Answer
    C. 0.70
    Explanation
    The strength reduction factor for axial compression and axial compression with flexure for tie reinforcement is 0.70. This factor represents the reduction in strength that is applied to the reinforcement when it is subjected to axial compression and flexure. It indicates that the tie reinforcement can withstand only 70% of its full strength when subjected to these combined forces.

    Rate this question:

  • 6.

    The strength reduction factor for bearing on concrete

    • A.

      0.75

    • B.

      0.70

    • C.

      0.85

    • D.

      0.90

    Correct Answer
    B. 0.70
    Explanation
    The strength reduction factor for bearing on concrete is 0.70. This factor is used to reduce the ultimate bearing capacity of the concrete in structural design calculations. It takes into account various factors such as the type and condition of the concrete, the load duration, and the safety requirements. A reduction factor of 0.70 indicates that the ultimate bearing capacity of the concrete is reduced by 30% for design purposes.

    Rate this question:

  • 7.

    The slenderness ratio L/r preferably should not exceed _____ for members whose design is based on COMPRESSIVE FORCE

    • A.

      200

    • B.

      300

    • C.

      250

    • D.

      400

    Correct Answer
    A. 200
    Explanation
    The slenderness ratio L/r refers to the ratio of the length of a member to its radius of gyration. For members designed under compressive force, a lower slenderness ratio is preferred as it indicates a more compact and stable member. Therefore, a slenderness ratio of 200 is the most preferable option among the given choices.

    Rate this question:

  • 8.

    The slenderness ratio L/r preferably should not exceed _____ for members whose design is based on TENSILE FORCE

    • A.

      250

    • B.

      200

    • C.

      400

    • D.

      300

    Correct Answer
    D. 300
    Explanation
    The slenderness ratio L/r preferably should not exceed 300 for members whose design is based on tensile force. This means that the length of the member (L) should not be more than 300 times its radius of gyration (r). If the slenderness ratio exceeds this value, the member may become more prone to buckling or failure under tensile forces. Therefore, it is important to ensure that the slenderness ratio is kept below 300 to maintain the structural integrity of the member.

    Rate this question:

  • 9.

    The ratio L/r for lacing bars arranged in SINGLE system shall not exceed

    • A.

      200mm

    • B.

      300mm

    • C.

      250mm

    • D.

      140mm

    Correct Answer
    D. 140mm
    Explanation
    The correct answer is 140mm because the ratio L/r for lacing bars arranged in a SINGLE system should not exceed this value.

    Rate this question:

  • 10.

    The ratio L/r for lacing bars arranged in DOUBLE system shall not exceed

    • A.

      140mm

    • B.

      300mm

    • C.

      200mm

    • D.

      250mm

    Correct Answer
    C. 200mm
    Explanation
    The correct answer is 200mm. The ratio L/r for lacing bars arranged in a DOUBLE system should not exceed 200mm. This means that the length of the lacing bar (L) should not be more than 200 times its radius (r). This restriction ensures that the lacing bars are strong enough to provide adequate support and prevent any failure or collapse.

    Rate this question:

  • 11.

    For members bent about their STRONG or WEAK AXES, members with compact sections where the flanges continuously connected to web, the allowable bending stress is

    • A.

      0.60 fy

    • B.

      0.70 fy

    • C.

      0.75 fy

    • D.

      0.66 fy

    Correct Answer
    D. 0.66 fy
    Explanation
    For members bent about their strong or weak axes, members with compact sections where the flanges are continuously connected to the web, the allowable bending stress is 0.66 fy.

    Rate this question:

  • 12.

    For BOX type and TABULAR textural members that meet the non compact section requirements of section 502.6 the allowable bending stress is

    • A.

      0.75 fy

    • B.

      0.60 fy

    • C.

      0.70 fy

    • D.

      0.66 fy

    Correct Answer
    B. 0.60 fy
    Explanation
    The correct answer is 0.60 fy. This means that for BOX type and TABULAR textural members that meet the non compact section requirements of section 502.6, the allowable bending stress is 0.60 times the yield strength (fy) of the material.

    Rate this question:

  • 13.

    The MAXIMUM UNIT STRESS permitted for a material in the design of a structural member. Also called ALLOWABLE UNIT STRESS, WORKING STRESS

    • A.

      Maximum stress

    • B.

      Ultimate stress

    • C.

      Allowable stress

    • D.

      Stress

    Correct Answer
    C. Allowable stress
    Explanation
    The given correct answer is "Allowable stress". Allowable stress refers to the maximum unit stress that is permitted for a material in the design of a structural member. It is also known as working stress or maximum unit stress. This stress limit ensures that the material does not exceed its capacity and remains within a safe range to prevent failure or deformation. By considering the properties and characteristics of the material, engineers determine the allowable stress to ensure the structural integrity and safety of the member.

    Rate this question:

  • 14.

    A graphic representation of the relationship between unit stress values and the corresponding unit strains for a specific material

    • A.

      Tensile Diagram

    • B.

      Moment Diagram

    • C.

      Ultimate strength Diagram

    • D.

      Stress-Strain Diagram

    Correct Answer
    D. Stress-Strain Diagram
    Explanation
    A stress-strain diagram is a graphic representation that shows the relationship between unit stress values and the corresponding unit strains for a specific material. It provides valuable information about the material's behavior under tension, including its elastic and plastic deformation properties, as well as its ultimate strength. The diagram typically consists of a linear elastic region, where stress and strain are directly proportional, followed by a yield point and a plastic deformation region. The stress-strain diagram is widely used in engineering to analyze and design structures and materials.

    Rate this question:

  • 15.

    The property of a material that enables it to DEFORM in response to an applied force and to recover its original size and shape upon removal force

    • A.

      Elasticity

    • B.

      Malleability

    • C.

      Toughness

    • D.

      Ductility

    Correct Answer
    A. Elasticity
    Explanation
    Elasticity is the property of a material that allows it to deform when a force is applied and then return to its original shape and size when the force is removed. This means that the material can stretch or compress under stress, but it will not permanently change its shape or size. Malleability refers to a material's ability to be easily shaped or formed by hammering or rolling. Toughness is the ability of a material to resist breaking or fracturing under stress. Ductility is the property of a material to be stretched into a wire without breaking.

    Rate this question:

  • 16.

    The property of the material that enables it to under go PLASTIC DEFORMATION after being stressed beyond the elastic limit and before rupturing.

    • A.

      Toughness

    • B.

      Ductility

    • C.

      Malleability

    • D.

      Elasticity

    Correct Answer
    B. Ductility
    Explanation
    Ductility is the property of a material that allows it to undergo plastic deformation after being stressed beyond the elastic limit and before rupturing. This means that a ductile material can be stretched or drawn into a wire or thread without breaking. It is a measure of how easily a material can be deformed under tensile stress.

    Rate this question:

  • 17.

    The property of a material that enables it to absorb energy before rupturing.

    • A.

      Malleability

    • B.

      Elasticity

    • C.

      Toughness

    • D.

      Ductility

    Correct Answer
    C. Toughness
    Explanation
    Toughness refers to the property of a material that allows it to absorb energy before rupturing. It indicates the ability of a material to withstand impact or shock without breaking or fracturing. A tough material can deform and absorb a significant amount of energy before reaching its breaking point. This property is important in various applications, such as in engineering and construction, where materials need to withstand high stress and impact forces.

    Rate this question:

  • 18.

    The maximum stress than can be attained immediately before actual failure or rupture

    • A.

      Yield point

    • B.

      Elastic limit

    • C.

      Proportional limit

    • D.

      Ultimate Strength

    Correct Answer
    D. Ultimate Strength
    Explanation
    Ultimate Strength refers to the maximum stress that a material can withstand before it fails or ruptures. It represents the point at which the material experiences complete failure and is unable to bear any further load. Unlike the yield point, elastic limit, and proportional limit, the ultimate strength is not a measure of the material's ability to return to its original shape after the stress is removed. Instead, it indicates the maximum stress that the material can sustain before breaking, making it a critical factor in determining the material's overall strength and durability.

    Rate this question:

  • 19.

    Maximum stress which the material springs back to the original length when the load is released

    • A.

      Proportional Limit

    • B.

      Elastic Limit

    • C.

      Yield Point

    • D.

      Ultimate Strength

    Correct Answer
    A. Proportional Limit
    Explanation
    The proportional limit is the maximum stress at which a material can be loaded and still return to its original length when the load is released. Beyond this point, the material will experience permanent deformation. The elastic limit refers to the maximum stress at which a material can be loaded and still return to its original shape after the load is released. The yield point is the stress at which a material starts to deform plastically. The ultimate strength is the maximum stress a material can withstand before it fails. Therefore, the best fit for the given explanation is the proportional limit.

    Rate this question:

  • 20.

    The stress where in the deformation increases without any increase in load.

    • A.

      Ultimate Strength

    • B.

      Yield Point

    • C.

      Proportional Limit

    • D.

      Elastic Limit

    Correct Answer
    B. Yield Point
    Explanation
    The yield point is the stress at which a material begins to exhibit permanent deformation without any increase in load. It is the point at which the material transitions from elastic behavior to plastic behavior. At the yield point, the material has reached its maximum strength and any further increase in stress will result in permanent deformation. This is different from the proportional limit, which is the point at which the material behaves elastically and deformation is directly proportional to the applied load. The ultimate strength is the maximum stress a material can withstand before failure, and the elastic limit is the maximum stress at which a material can be stressed and still return to its original shape when the load is removed.

    Rate this question:

  • 21.

    The gradual deformation of a body produced by a continued application of stress or prolonged exposure to heat

    • A.

      Creep

    • B.

      Fatigue

    • C.

      Strain

    • D.

      Elastic Range

    Correct Answer
    A. Creep
    Explanation
    Creep is the correct answer because it refers to the gradual deformation of a body caused by the continuous application of stress or prolonged exposure to heat. This process occurs over time and leads to a permanent change in the shape or structure of the material. Creep is commonly observed in materials such as metals, plastics, and geological formations, and it is influenced by factors such as temperature, stress level, and time.

    Rate this question:

  • 22.

    The act of stretching or state of being pulled apart, resulting in the elongation of an elastic body

    • A.

      Compression

    • B.

      Tension

    • C.

      Stress

    • D.

      Force

    Correct Answer
    B. Tension
    Explanation
    Tension refers to the act of stretching or being pulled apart, causing the elongation of an elastic body. It is a force that acts in opposite directions and stretches or pulls an object. In contrast, compression refers to the act of pressing or squeezing an object, resulting in its shortening or reduction in size. Stress, on the other hand, is the force per unit area that is applied to an object, causing deformation. While force is a general term for a push or pull, tension specifically refers to the stretching or pulling apart of an object.

    Rate this question:

  • 23.

    A tensile or compressive force acting along the longitudinal axis of a structural member and a the centroid of the cross section, producing axial stress without bending, torsion or shear also called AXIAL LOAD

    • A.

      Axial Force

    • B.

      Tensile Force

    • C.

      Compressive Force

    • D.

      Eccentric Force

    Correct Answer
    A. Axial Force
    Explanation
    An axial force refers to a tensile or compressive force that is applied along the longitudinal axis of a structural member. This force acts through the centroid of the cross section, resulting in axial stress without any bending, torsion, or shear. In other words, the force is directly applied in a straight line along the length of the member, causing it to either stretch or compress. This type of force is also commonly known as an axial load.

    Rate this question:

  • 24.

    The ratio of lateral strain to the corresponding longitudinal strain in an elastic body under longitudinal stress

    • A.

      Slenderness ratio

    • B.

      Poisson's Ratio

    • C.

      Compressive Ratio

    • D.

      Axial Ratio

    Correct Answer
    B. Poisson's Ratio
    Explanation
    Poisson's Ratio is the correct answer because it represents the ratio of lateral strain to the corresponding longitudinal strain in an elastic body under longitudinal stress. It is a fundamental property of materials that describes how they deform when subjected to stress. Poisson's Ratio is a dimensionless quantity and is always between -1 and 0.5 for most common materials. A value of 0.5 represents a material that does not change in lateral dimensions at all, while a negative value indicates that the material expands laterally when compressed longitudinally.

    Rate this question:

  • 25.

    The axial stress that develops at the cross section of an elastic body to resist the

    • A.

      Tensile stress

    • B.

      Compressive stress

    • C.

      Stress

    • D.

      Tension

    Correct Answer
    B. Compressive stress
    Explanation
    Compressive stress refers to the stress that occurs when a force is applied to an object, causing it to be compressed or squeezed. In the context of an elastic body, when a compressive stress is applied, it creates an axial stress at the cross section of the body. This axial stress is developed to resist the compressive stress and prevent the body from collapsing or deforming under the applied force. Therefore, the correct answer is compressive stress.

    Rate this question:

  • 26.

    The shortening of a unit length of material produced by a compressive stress

    • A.

      Compressive stress

    • B.

      Compressive strain

    • C.

      Tension

    • D.

      Strain

    Correct Answer
    B. Compressive strain
    Explanation
    Compressive strain refers to the reduction in length of a material when subjected to compressive stress. When a material is compressed, it experiences a decrease in length due to the applied force. This phenomenon is known as compressive strain. It is the opposite of tension, where a material elongates under tensile stress. Therefore, the given answer correctly identifies the term that describes the shortening of a unit length of material produced by compressive stress.

    Rate this question:

  • 27.

    The lateral deformation produced in a body by an external force that causes one part of the body to slide relative to an adjacent part in a direction parallel to their plane contact

    • A.

      Shear

    • B.

      Bending

    • C.

      Stress

    • D.

      Strain

    Correct Answer
    A. Shear
    Explanation
    Shear is the correct answer because it refers to the lateral deformation that occurs when an external force causes one part of a body to slide relative to an adjacent part in a direction parallel to their plane contact. This type of deformation is commonly seen in materials like metal or concrete when subjected to forces that cause them to slide or deform sideways. Shear stress and shear strain are used to measure and quantify this type of deformation in materials.

    Rate this question:

  • 28.

    A projecting beam supported at only one fixed end

    • A.

      Simple Beam

    • B.

      Cantilever Beam

    • C.

      Over hanging Beam

    • D.

      Fixed End Beam

    Correct Answer
    B. Cantilever Beam
    Explanation
    A cantilever beam is a projecting beam that is supported at only one fixed end. It is a type of beam that extends horizontally from a support structure, with the other end free to move. This type of beam is commonly used in construction and engineering to create overhangs or to support structures where one end needs to be fixed while the other end is free.

    Rate this question:

  • 29.

    A beam resisting on simple supports at both ends which are free to rotate and have no moment  resistance

    • A.

      Fixed end beam

    • B.

      Simple Beam

    • C.

      Cantilever

    • D.

      Overhanging Beam

    Correct Answer
    B. Simple Beam
    Explanation
    A simple beam is a beam that is supported on simple supports at both ends, which are free to rotate and have no moment resistance. This means that the beam can freely rotate at both ends and does not have any resistance to bending moments.

    Rate this question:

  • 30.

    A simple beam extending beyond one of its support.this reduces positive moment at midspan while developing a negative moment at the base of the cantilever over the support

    • A.

      Cantilever

    • B.

      Overhanging beam

    • C.

      Fixed End Beam

    • D.

      Simple Beam

    Correct Answer
    B. Overhanging beam
    Explanation
    An overhanging beam refers to a type of beam that extends beyond one of its supports. This design reduces the positive moment (bending) at the midspan of the beam, while creating a negative moment (opposite bending) at the base of the cantilever over the support. This configuration allows the beam to distribute the load more effectively and provides stability to the structure. Therefore, the answer "Overhanging beam" is the correct choice based on the given explanation.

    Rate this question:

  • 31.

    A beam extending over more than 2 supports in order to develop greater rigidity and smaller moments than a series of simple beams having similar spans and loading.

    • A.

      Simple beam

    • B.

      Continuous Beam

    • C.

      Cantilever Beam

    • D.

      Overhanging Beam

    Correct Answer
    B. Continuous Beam
    Explanation
    A continuous beam is a beam that extends over more than 2 supports, which helps to develop greater rigidity and smaller moments compared to a series of simple beams with similar spans and loading. By having multiple supports, the beam can distribute the load more evenly, reducing the bending moments and increasing its overall stability. This makes continuous beams suitable for longer spans and heavier loads, as they can better withstand the forces acting upon them.

    Rate this question:
